Siemens 6SL3210-1PC22-2UL0
Overview
The Siemens 6SL3210-1PC22-2UL0 is part of the SINAMICS G120C family—compact, versatile frequency converters for controlling induction motors. This model offers an 11 kW power rating, built-in I/O, and standard communication protocols, designed for fast installation and efficient operation in industrial environments.
Key Features
-
Rated power: 11 kW (15 HP)
-
Input voltage: 3AC 380–480 V ±10%
-
Integrated EMC filter Class A
-
Integrated braking chopper
-
Built-in I/O: 6 DI / 2 DO / 2 AI / 1 AO
-
Integrated RS485 / USS / Modbus RTU communication
-
Compact and space-saving design
-
Easy commissioning via USB or BOP-2/IOP
Technical Specifications
-
Siemens Code: 6SL3210-1PC22-2UL0
-
Power Rating: 11 kW / 15 HP
-
Rated Output Current: 25.4 A
-
Input Voltage: 3AC 380–480 V ±10%
-
Overload Capacity: 150% for 60s (LO), 200% for 3s
-
Braking Chopper: Integrated
-
Cooling Method: Air-cooled
-
Protection Class: IP20
-
Ambient Temperature: −10 °C to +50 °C (derating above 40 °C)
-
Dimensions (HxWxD): Approx. 380 × 140 × 203 mm
Applications
-
Pumps and fans
-
Conveyor systems
-
Compressors
-
Material handling
-
General machinery in discrete industries
Why Choose Siemens 6SL3210-1PC22-2UL0?
-
Compact footprint for panel integration
-
All-in-one drive with I/O, filter, and braking chopper
-
Flexible communication and fast setup
-
Siemens reliability and energy efficiency
-
Cost-effective solution for standard drives
Order Now
Optimize your motor control system with the Siemens 6SL3210-1PC22-2UL0 – a robust and compact inverter for everyday industrial applications.
Return to the Siemens Sinamics Drives collection to explore more options including V20, G120, G130, G150, and S120 series for advanced industrial motor control.
You can also browse the Siemens Variable Frequency Drives (VFDs) main category to view the complete Siemens portfolio of Sinamics, Micromaster, and SIMOVERT VFDs.
