Siemens 6SL3210-1KE24-4AF1
Overview
The Siemens 6SL3210-1KE24-4AF1 is part of the SINAMICS G120X series, designed for use in infrastructure sectors such as water treatment and HVAC. With its rugged build, integrated functions and cloud connectivity via SINAMICS Connect, it offers efficient, future-ready motor control.
Key Features
-
Rated power: 7.5 kW (10 HP)
-
3-phase input: 3AC 380–480 V ±10%
-
Output frequency: 0–599 Hz
-
Built-in EMC filter (Category C2)
-
Integrated STO (Safe Torque Off)
-
Conformal coating for harsh environments
-
RS485 and optional PROFINET/Modbus TCP
-
IP20 enclosure, compact design
-
Optimized for pumps, fans, and compressors
Technical Specifications
-
Siemens Code: 6SL3210-1KE24-4AF1
-
Input Voltage: 3AC 380–480 V
-
Power Rating: 7.5 kW
-
Rated Output Current: ~17 A
-
Overload Capacity: 110% for 60 s, 150% for 3 s
-
Cooling: Internal fan
-
Protection Class: IP20
-
Temperature Range: -10 °C to +60 °C
-
Certifications: CE, UL, cUL, RoHS
-
Interfaces: RS485, with expansion options
Applications
-
Water and wastewater systems
-
Heating, ventilation, and air conditioning (HVAC)
-
Building automation
-
Irrigation systems
-
Municipal pumping stations
Why Choose Siemens 6SL3210-1KE24-4AF1?
-
Designed specifically for infrastructure needs
-
Long lifecycle and maintenance-friendly
-
Fast installation and commissioning
-
Seamless cloud integration for monitoring
-
Backed by Siemens reliability and global service
Order Now
Maximize efficiency in your water, HVAC, or infrastructure systems with the SINAMICS G120X inverter 6SL3210-1KE24-4AF1.
Return to the Siemens Sinamics Drives collection to explore more options including V20, G120, G130, G150, and S120 series for advanced industrial motor control.
You can also browse the Siemens Variable Frequency Drives (VFDs) main category to view the complete Siemens portfolio of Sinamics, Micromaster, and SIMOVERT VFDs.
